S5024PV5-EI-HPWR 启动不起来,上电后风扇狂转,仅系统灯橙色常亮,链接console敲回车显示:
EXTENDED BOOT MENU
1. Download image to flash
2. Select image to boot
3. Display all files in flash
4. Delete file from flash
5. Restore to factory default configuration
6. Enter BootRom upgrade menu
7. Skip current system configuration
8. Set switch startup mode
9. Set The Operating Device
0. Reboot
Ctrl+Z: Access EXTENDED ASSISTANT MENU
Ctrl+F: Format file system
Ctrl+P: Change authentication for console login
Ctrl+R: Download image to SDRAM and run
Ctrl+C: Display Copyright
Enter your choice(0-9):
//键入3,显示:
Display all file(s) in flash:
File Number File Size(bytes) File Name
================================================================================
Free space: 254672896 bytes
The current image is s5000v5_ei-cmw710-boot-r6319p01.bin
(*)-with main attribute
(b)-with backup attribute
(*b)-with both main and backup attribute
//明显这个bin文件不是这个交换机的文件,交换机是旧的,忘记了配置,需要重新配置使用,找了运营商的工程师帮忙让调试一下,结果整成这样了,好像记得他往交换机里面ftp过文件,试了几次都没成,我这几天闲下来了,寻思着琢磨琢磨。
//如果键入5“恢复出厂配置”的话,显示:
Password recovery capability is enabled. To perform this operation, first
disable the password recovery capability using the undo password-recovery
enable command in CLI.
请各位大神指导。。。。。。。
