vrrp 双主 故障

您好，看了下配置，给你做了个脚本，参考

最终标准配置
# 上行接口（不变）
interface GigabitEthernet1/0/0
port link-mode route
description dianxin
ip address 192.168.201.66 255.255.255.252
quit

# NQA探测（优化后）
nqa entry admin test
type icmp-echo
destination ip 192.168.201.65
frequency 2000
reaction 1 checked-element probe-fail threshold-type consecutive 10 action-type trigger-only
quit
nqa schedule admin test start-time now lifetime forever

# Track联动（优化后）
track 1 nqa entry admin test reaction 1

# VRRP绑定接口（完整优化）
interface GigabitEthernet1/0/13
port link-mode route
description lan
ip address 192.168.1.3 255.255.255.0
vrrp vrid 1 virtual-ip 192.168.1.1 255.255.255.0
vrrp vrid 1 priority 110
vrrp vrid 1 track 1 priority reduced 15
vrrp vrid 1 preempt-mode timer delay 3
vrrp vrid 1 timer advertise 2
quit
路由器 B 最终完整配置（备网关，优先级稍低，对称联动上行）
# 上行接口（补充完整，和A对应，根据B实际上行配置，此处参考A格式）
interface GigabitEthernet1/0/0
port link-mode route
description dianxin
ip address 192.168.201.x 255.255.255.252 # 替换为B的实际上行IP
quit

# NQA探测（和A对称）
nqa entry admin test
type icmp-echo
destination ip 192.168.201.65 # 替换为B的实际上行网关
frequency 2000
reaction 1 checked-element probe-fail threshold-type consecutive 10 action-type trigger-only
quit
nqa schedule admin test start-time now lifetime forever

# Track联动（和A对称）
track 1 nqa entry admin test reaction 1

# VRRP绑定接口（完整优化）
interface GigabitEthernet1/0/13
port link-mode route
description lan
ip address 192.168.1.2 255.255.255.0
vrrp vrid 1 virtual-ip 192.168.1.1 255.255.255.0
vrrp vrid 1 priority 100
vrrp vrid 1 track 1 priority reduced 15
vrrp vrid 1 preempt-mode timer delay 5
vrrp vrid 1 timer advertise 2
quit
