防火墙用二层接口，设备ping不通

#

 version 7.1.064, Alpha 7164

#

 sysname H3C

#

context Admin id 1

#

 telnet server enable

#

 irf mac-address persistent timer

 irf auto-update enable

 undo irf link-delay

 irf member 1 priority 1

#

 xbar load-single

 password-recovery enable

 lpu-type f-series

#

vlan 1

#

vlan 10

#

interface NULL0

#

interface GigabitEthernet1/0/0

 port link-mode route

 combo enable copper

 ip address 192.168.1.1 255.255.255.0

#

interface GigabitEthernet1/0/3

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/4

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/5

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/6

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/7

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/8

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/9

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/10

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/11

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/12

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/13

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/14

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/15

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/16

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/17

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/18

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/19

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/20

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/21

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/22

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/23

 port link-mode route

 combo enable copper

#

interface GigabitEthernet1/0/1

 port link-mode bridge

 port access vlan 10

 combo enable copper

#

interface GigabitEthernet1/0/2

 port link-mode bridge

 port access vlan 10

 combo enable copper

#

security-zone name Local

#

security-zone name Trust

 import interface GigabitEthernet1/0/1 vlan 10

#

security-zone name DMZ

#

security-zone name Untrust

 import interface GigabitEthernet1/0/2 vlan 10

#

security-zone name Management

 import interface GigabitEthernet1/0/0

#

 scheduler logfile size 16

#

line class aux

 user-role network-operator

#

line class console

 user-role network-admin

#

line class tty

 user-role network-operator

#

line class vty

 user-role network-operator

#

line aux 0

 user-role network-admin

#

line con 0

 authentication-mode scheme

 user-role network-admin

#

line vty 0 4

 authentication-mode scheme

 user-role network-admin

#

line vty 5 63

 user-role network-operator

#

 info-center loghost 127.0.0.1 port 3301 format default

 info-center source CFGLOG loghost level informational

#

domain system

#

 aaa session-limit ftp 16

 aaa session-limit telnet 16

 aaa session-limit ssh 16

 domain default enable system

#

role name level-0

 description Predefined level-0 role

#

role name level-1

 description Predefined level-1 role

#

role name level-2

 description Predefined level-2 role

#

role name level-3

 description Predefined level-3 role

#

role name level-4

 description Predefined level-4 role

#

role name level-5

 description Predefined level-5 role

#

role name level-6

 description Predefined level-6 role

#

role name level-7

 description Predefined level-7 role

#

role name level-8

 description Predefined level-8 role

#

role name level-9

 description Predefined level-9 role

#

role name level-10

 description Predefined level-10 role

#

role name level-11

 description Predefined level-11 role

#

role name level-12

 description Predefined level-12 role

#

role name level-13

 description Predefined level-13 role

#

role name level-14

 description Predefined level-14 role

#

user-group system

#

local-user admin class manage

 password hash $h$6$EH5lhU1PrwGLafz5$wqmb9S+vy3f8f8D8Cimsdi26li9/ZLiJYYtyuI4JzcR/K4TEYLxuMdcZR/U6bBNNG5yQiC0R4B66L0G1zXanjA==

 service-type telnet terminal http https

 authorization-attribute user-role level-3

 authorization-attribute user-role network-admin

 authorization-attribute user-role network-operator

#

 ip http enable

 ip https enable

#

security-policy ip

 rule 0 name any

  action pass

#

return
